Dot Laser Modules
Lasermate
Group, Inc. specializes in design and manufacturing high quality and low cost laser diode modules for OEM users. We offer blue, green, visible red and infrared dot laser modules with circular and elliptical beam profiles in variety of packages and configurations offering at very competitive prices. Our laser modules are fully self-contained with laser diode, optics, and power supply. More than 150 types of OEM laser modules have been designed and manufactured for our
customers. Designed for OEM, our laser modules are ideal for a wide range of low power laser applications, such as positioning, alignment, measurement, bar code reader and robotic control. From general sighting applications to
OEM projects, we confidently meet your cost-performance requirements.
| Image |
Model
Series |
Data
Sheet |
Description |
Wavelength |
Output
Power |
Laser
Class |
Operating
Current |
Operating
Voltage |
Dimensions |
|
|
GMP450 |
 |
450nm Blue Dot Laser Diode Modules
|
450nm |
0.5-0.99mW, 3-4.99mW |
II, IIIa |
<300mA |
3-5V DC |
Dia.
12mm x L. 44.5mm |
|
|
GMP515 |
|
515nm Green Dot Laser
Diode Modules
|
515nm |
0.5-0.99mW, 3-4.99mW |
II, IIIa |
250mA@3VDC; 150mA@5VDC |
3-5V DC |
Dia. 12mm x L. 35.5mm |
|
|
PLA515 |
|
Pre-aligned 515nm <5mW Class IIIa Green
Dot Laser
Diode Modules with <+/-0.05 degree Beam centering
|
515nm |
<5mW |
IIIa |
180mA |
3-5V DC |
Dia. 10.5mm x L. 33.5mm |
 |
GMY532 |
|
532nm Green Dot DPSS Laser
Modules - Smallest size Dia. 8mm x L. 50.7mm, APC with pulse
function
|
532nm |
0.4-4.99mW |
II, IIIa |
140mA |
3V DC |
Dia. 8mm x L.
50.7mm |
 |
GMP532 |
|
532nm Green Dot DPSS Laser
Modules - Dia. 12mm
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
3V DC |
Dia. 12mm x L.
47.3mm or 51.3mm |
 |
GMP532-A |
|
532nm Green Dot DPSS Laser
Modules - Dia. 13mm x 52mm, Adjustable Focus
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
3V DC |
Dia. 13mm x L. 52mm |
 |
GMP532-J |
|
532nm Green Dot DPSS Laser
Modules - Dia. 12mm x 55.3mm, IEC 60825-1, EN 60825-1 & JQA
Compliance
|
532nm |
0.5-0.99 |
II |
<0.30A |
3V DC |
Dia. 12mm x L.
55.3mm |
 |
GMC532 |
|
532nm Green Dot DPSS Laser
Modules - Dia. 20mm x 58.5mm, TTL Modulation up to 1kHz
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
9-15V DC |
Dia. 20mm x 58.5mm
(Laser head) |
 |
GMD532 |
|
532nm Green Dot DPSS Laser
Modules with Dia. 20mm x 60mm, Fixed Focus
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
3V DC or 5V DC |
Dia. 20mm x L. 60mm |
 |
GMD532-A |
|
532nm Green Dot DPSS Laser
Modules with Dia. 20mm x 70.5mm, Adjustable Focus
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
3V DC or 5V DC |
Dia. 20mm x L.
70.5mm |
 |
GME532 |
|
532nm Green Dot DPSS Laser
Modules, 50mm x 21mm x 21mm, Fixed Focus
|
532nm |
0.5-20mW |
II,
IIIa, IIIb |
<0.30A |
9-15V DC |
50mm x 21mm x 21mm
(Laser head) |
 |
GMF532 |
|
532nm Green Dot DPSS Laser
Modules, 50mm x 50mm x 34mm, Soft-Start Protection, TTL Modulation
up to 1kHz
|
532nm |
Up to >50mW |
II,
IIIa, IIIb |
<0.3A for
<5mW, <0.4A for >30mW, <0.65A for >50mW |
9V DC |
50mm x 50mm x 34mm
(Laser head) |
 |
SL |
|
635nm-650nm Compact Dot Laser Diode
Modules - Dia. 4mm x L. 8.5mm
|
635nm,
650nm |
Up to <3mW |
II, IIIa |
<35mA |
3V DC |
Dia. 4mm x L. 8.5mm |
 |
PPA |
|
650nm Miniature Dot Laser
Diode Modules - Dia. 6.5mm x L. 14.5mm, Plastic Housing
|
650nm |
Up to <3mW |
II, IIIa |
26mA |
2.5-3.3V DC |
Dia. 6.5mm x L.
14.5mm |
 |
LLP |
|
650nm Miniature Laser Diode
Module, Dia. 9mm x L. 18.3mm
|
650nm |
0.7-0.99mW |
II |
<40mA |
3-4.5V DC |
Dia. 9mm x L.
18.3mm |
 |
PLA650 |
|
Pre-aligned 650nm <5mW Class IIIa
Red Dot Laser
Diode Modules with <+/-0.05 degree Beam centering for Alignment
application
|
650nm |
4.5mW |
IIIa |
30mA |
3V DC |
Dia. 10.5mm x L.
15.5mm |
 |
PMS |
|
635nm-980nm Miniature Dot
Laser Diode Modules - Dia. 6mm x L. 24.3mm
|
635-980nm |
0.5-6mW |
II,
IIIa, IIIb |
25-50mA |
3-6V DC |
Dia. 6mm x L.
24.3mm |
 |
LSP |
|
635nm-980nm Miniature Dot
Laser Diode Modules - Dia. 8mm x L. 12.5mm
|
635-980nm |
0.5-6mW |
II,
IIIa, IIIb |
25-40mA |
3-6V DC |
Dia. 8mm x L.
12.5mm |
 |
PSP |
|
650nm Red Dot Laser
Diode Modules - Dia. 8mm x L. 25.7mm, IEC 60825-1, EN 60825-1, JQA
|
650nm |
0.5-0.99mW |
II |
33mA for 635nm;
25mA for 650nm |
3-9V DC |
Dia. 8mm x L.
25.7mm |
 |
PSC |
|
650nm Red Dot Laser
Diode Modules - Dia. 8mm x L. 29mm, IEC 60825-1, EN 60825-1, JQA
|
650nm |
0.5-0.99mW |
II |
33mA for 635nm;
25mA for 650nm; 38mA for 670nm |
3-9V DC |
Dia. 8mm x L. 29mm |
 |
PLP |
|
635nm-980nm Miniature Dot
Laser Diode Modules - Dia. 10.5mm x L. 15mm, Adjustable or Fixed
Focus
|
635-980nm |
0.5-6mW |
II,
IIIa, IIIb |
25-50mA |
3-6V DC |
Dia. 10.5mm x L.
15mm |
 |
PLC |
|
635nm-980nm Miniature Dot
Laser Diode Modules - Dia. 10.5mm x L. 19.3mm, Adjustable or Fixed
Focus
|
635-980nm |
0.5-4mW |
II,
IIIa, IIIb |
25-50mA |
3-6V DC |
Dia. 10.5mm x L.
19.3mm |
 |
PLG |
|
635nm-980nm Miniature Dot
Laser Diode Modules - Dia. 10.5mm x L. 20.5mm, Adjustable or Fixed
Focus
|
635-980nm |
0.5-7mW |
II,
IIIa, IIIb |
25-50mA |
3-6V DC |
Dia. 10.5mm x L.
20.5mm |
 |
LJP |
|
635nm-980nm Prime Dot Laser
Diode Modules - Dia. 12mm x L. 29mm, Adjustable Focus
|
635-980nm |
0.5-6mW |
II,
IIIa, IIIb |
25-40mA |
3-6V DC |
Dia. 12mm x L. 29mm |
 |
LTG |
|
High Performance 635nm-980nm
Laser Diode Modules - Dia. 0.5in x L. 2in, Elliptical Beam
|
635-980nm |
0.5-50mW |
II,
IIIa, IIIb |
30-125mA |
4.5-6V DC or 4.5-9V
DC |
Dia. 0.5in x L. 2in |
 |
LTC |
|
High Performance 635nm-980nm
Laser Diode Modules - Dia. 0.5in x L. 2in, Circular Round Beam
|
635-980nm |
0.5-25mW |
II,
IIIa, IIIb |
30-125mA |
4.5-6V DC or 4.5-9V
DC |
Dia. 0.5in x L. 2in |
 |
LTG-A24 |
|
635nm-980nm
Laser Diode Modules with 24-28VDC Operating Voltage - Dia. 0.5in x L. 2in, Elliptical Beam
|
635-980nm |
0.5-16mW |
II,
IIIa, IIIb |
|
24-28V DC |
Dia. 0.5in x L. 2in |
 |
LTC-A24 |
|
635nm-980nm
Laser Diode Modules with 24-28VDC Operating Voltage - Dia. 0.5in x L. 2in, Circular Round Beam
|
635-980nm |
0.5-8mW |
II,
IIIa, IIIb |
|
24-28V DC |
Dia. 0.5in x L. 2in |
 |
LXG |
|
High Performance 635nm-980nm
Laser Diode Modules - Dia. 0.5in x L. 2in, Elliptical Beam,
DC-Jack Connector
|
635-980nm |
0.5-45mW |
II,
IIIa, IIIb |
30-90mA |
4.5-6V DC or 4.5-9V
DC |
Dia. 0.5in x L. 2in |
 |
LXC |
|
High Performance 635nm-980nm
Laser Diode Modules - Dia. 0.5in x L. 2in, Circular Round Beam,
DC-Jack Connector
|
635-980nm |
0.5-14mW |
II,
IIIa, IIIb |
30-90mA |
4.5-6V DC or 4.5-9V
DC |
Dia. 0.5in x L. 2in |
 |
LAC |
|
Precision Pointing 635nm-980nm
Dot Laser Diode Modules
|
635-980nm |
0.5-4mW |
II,
IIIa, IIIb |
25-50mA |
3-6V DC |
Dia. 15.9mm x L.
47mm |
 |
GMR1064 |
|
1064nm Infrared Dot DPSS Laser
Modules, 50mm x 21mm x 21mm, TTL modulation up to 1kHz
|
1064nm |
3-100mW |
IIIb |
<0.4A for
<50mW; <0.6A for >100mW |
9-15V DC |
50mm x 21mm x 21mm
(Laser head) |
 |
GMF1064 |
|
1064nm Infrared Dot DPSS Laser
Modules, TTL modulation up to 1kHz
|
1064nm |
<200mW (~180mW) |
IIIb |
<0.75A |
9V DC |
|
| |
|
