10Gbps 1310 nm MQW DFB Laser Diode in LC Receptacle
Module
Model
No. T13D-R-LCMS-10G
Features
-
Uncooled DFB Laser diode with
multi-quantum-well structure
-
Built-in
InGaAs PIN photodiode
-
Hermetically
sealed active component
-
Low threshold current
-
LC receptacle package
Applications
-
10G BASE-LR/LW
-
10G Fiber Channel
Absolute Maximum Rating (Tc=25 oC)
|
|
Parameter
|
Symbol
|
Value
|
Unit
|
Peak
Optical Output Power
|
Po
|
5
|
mW
|
LD
Reverse Voltage
|
VRLD
|
2
|
V
|
PD
Forward Current
|
IFPD
|
2
|
mA
|
PD
Reverse Voltage
|
VRPD
|
20
|
V
|
Operating
Case Temperature
|
Top
|
-20~+85
|
oC
|
Storage
Temperature
|
Tstg
|
-40~+85
|
oC
|
| Soldering temperature (10 sec.) |
Stemp |
260 |
oC |
|
Optical and Electrical Characteristics(Tc=25 oC)
|
Parameter
|
Symbol
|
Min.
|
Typ.
|
Max.
|
Unit
|
Test
condition
|
|
Threshold
Current
|
Ith
|
-
|
10
|
15
|
mA
|
CW
|
| Fiber
Output Power |
Pf
|
0.5
|
-
|
1.5
|
mW
|
CW, Ith+ 25mA
|
|
Operating
Voltage
|
Vop
|
-
|
-
|
2
|
V
|
CW, If
=30mA
|
|
Peak
Wavelength
|
lc
|
1295
|
1310
|
1320
|
nm
|
CW, If
=30mA
|
|
Slope efficiency
|
Se
|
0.02
|
-
|
0.06
|
mW/mA
|
CW
|
|
Side Mode Suppression Ratio
|
SMSR
|
30
|
-
|
-
|
dB
|
|
|
Forward Voltage
|
VF
|
-
|
1.5
|
-
|
V
|
CW,
@ Iop
|
|
Rise
Time, 20~80%1
|
tr
|
-
|
-
|
40
|
ps
|
Ib = Ith, 20%~80%,
|
|
Fall
Time, 20~80%1
|
tf
|
-
|
-
|
50
|
ps
|
Ib = Ith, 80%~20%,
|
|
Tracking
Error
|
DPf/Pf
|
-
|
+/-1.5
|
-
|
dB
|
APC, 0 oC ~+70 oC
|
|
PD
Monitor Current
|
Im
|
0.05
|
-
|
-
|
mA
|
CW, If
=30mA
|
|
PD
Monitor Dark Current
|
Id
|
-
|
-
|
100
|
nA
|
VRPD=5V
|
| |
|
